Hikvision HWP-N2204IH-DE3 HiWatch Network PTZ Camera

€ 267,00
HiWatch Series: 2.0 Megapixel 4x IR Network PTZ Camera
Beschikbaarheid: Op voorraad
SKU
HWP-N2204IH-DE3(F)
  • 1/2.8" progressive scan CMOS
  • Up to 1920 × 1080@30fps resolution
  • Min. illumination:Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC ON), 0 Lux with IR
  • Up to 20 m IR distance
  • 4× optical zoom, 16× digital zoom
  • 120 dB WDR (Wide Dynamic Range)
  • Regional Exposure, Regional Focus
  • 3D DNR (Digital Noise Reduction)
  • Support H.265+/H.265 video compression
  • Built-in microphone
  • 12 VDC & PoE
  • IK10, IP66

Lees meer over / read more about Hikvision HiWatch series

Meer informatie
SKU HWP-N2204IH-DE3(F)
Merk Hikvision
EANcode 6931847157340
HWP-N2204IH-DE3
Camera
Image sensor 1/2.8" progressive scan CMOS
Min. Illumination Color: 0.005 Lux @(F1.6, AGC ON)
B/W: 0.001 Lux @(F1.6, AGC ON)
0 Lux with IR
White balance Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent
Lamp/Sodium Lamp
Gain Auto/Manual
Shutter Time 50Hz: 1/1 s to 1/30,000 s
60Hz: 1/1 s to 1/30,000 s
Day&Night IR cut filter
Digital Zoom 16x
Privacy Mask 24 programmable privacy masks
Focus Mode Auto/Semi-automatic/Manual
WDR (Wide Dynamic Range) 120 dB WDR
Lens
Focal length 2.8 to 12 mm, 4x optical zoom
Zoom speed App. 2x (optical lens, wide-tele)
Aperture Range F1.6 to F2.7
Field of View Horizontal Field of View: 109° to 34° (Wide-tele)
Vertical FoV 57° to 19° (Wide-tele)
Diagonal FoV 135° to 39° (Wide-tele)
Working distance 10 mm to 1500 mm (Wide-tele)
PTZ
Movement Range (Pan) 0° to 330°
Pan speed Configurable, from 0.1°/s to 100°/s,
Preset speed: 100°/s
Movement Range (Tilt) From 0° to 90°
Tilt Speed Configurable, from 0.1°/s to 100°/s
Preset Speed: 100°/s
Proportional Zoom Support
Presets 300
Power-off Memory Support
IR
IR Range Up to 20m
Smart IR Support
Compression standard
Video compression Main Stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG
H.264 type Baseline Profile/Main Profile/High Profile
H.264+ Support
H.265 type Main Profile
H.265+ Support
Video Bit Rate 32 Kbps to 16384 Kbps
Audio Compression G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)
Smart Feature-Set
Basic Event Motion Detection, Video Tampering Detection, Exception
Smart Event Face Detection, Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Object Removal Detection, Unattended Baggage Detection, Audio Exception Detection
Smart Record ANR (Automatic Network Replenishment), Dual-VCA
Region of Interest Main stream, sub-stream, and third stream respectively support two fixed areas
Max. Resolution 2 MP (1920 x 1080)
Main Stream
Max. Frame Rate
50Hz: 25fps (1920 × 1080, 1280 x 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 x 960, 1280 × 720)
Sub-stream
Max. Frame Rate
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream 50Hz: 25fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Image Enhancement 3D DNR, HLC, EIS, Regional Exposure, Regional Focus
Network
Network Storage Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/CIPS), ANR
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6 UDP, Bonjour
API Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party
Management Platform, support Hik-Connect
Simultaneous Live View Up to 20 channels
User/Host Up to 32 users
3 levels: Administrator, Operator and User
Security Measures User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
Client iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web browser IE, Chrome, Firefox
Interface
Network Interface 1 RJ45 10M/100M self-adaptive Ethernet port
Audio Interface 1-ch audio input and 1-ch audio output
General
Working temperature -20 °C to 60 °C
Working humidity 90% or less
Power Supply 12 VDC + PoE
Max 12W (max 3.9W for IR)
Protection level IP66 Standard, IK 10, TVS 4000V Lightning Protection, Surge Protection and Voltage
Transient Protection
Material Aluminum alloy, PC, PC+ABS
Dimensions Camera: Ø 130,7 mm × 101,7 mm
Weight Approx. 530 g



Of download de technische specificaties: datasheet HWP-N2204IH-DE3

Bekijk hier de handleiding van de netwerk PTZ camera.
Beide zijn ook te vinden onder Support/Downloads/Hikvision.
