Hikvision HWN-2104H-4P HiWatch Network Video Recorder

€ 181,29
HiWatch series: Network Video Recorder
Beschikbaarheid: Op voorraad
SKU
HWN-2104H-4P(C)
  • H.265+/H.265/H.264+/H.264 video compression
  • Up to 40 Mbps incoming bandwidth, and 60 Mbps outgoing bandwidth
  • Up to 4-ch network camera inputs
  • Up to 4-ch 1080p decoding capability
  • HDMI and VGA simultaneous output
  • Material: Plastic

Lees meer over / read more about Hikvision HiWatch series

Meer informatie
SKU HWN-2104H-4P(C)
Merk Hikvision
EANcode 6941264092223
Model   HWN-2104H-4P HWN-2108H-8P
Video Input IP Video Input 4-ch 8-ch
Up to 4 MP resolution
Network Incoming bandwith 40 Mbps 60 Mbps
Outgoing bandwith 60 Mbps
Video Output Recording resolution 4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
HDMI/VGA output resolution 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Decoding Decoding format H.265+/H.265/ H.264+/H.264
Live view/Playback resolution 4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Synchronous playback 4-ch 8-ch
Capability 1-ch @ 4 MP / 2-ch @ 1080p
Hard Disk SATA 1 SATA interface
Capacity Up to 6TB capacity for each disk
Network Management Network protocols TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP
External Interface Network interface 1 RJ-45 10/100Mbps self-adaptive Ethernet interface
USB interface 2 × USB 2.0
PoE Interface Interface 4, RJ-45 10/100 Mbps self-adaptive Ethernet interface 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power ≤ 36W ≤ 75W
Standard IEEE 802.3 af/at
General Power supply 48 VDC
Power ≤ 50W ≤ 90W
Consumption (without hard disk and PoE) ≤ 10 W
Working temperature -10 to +55º C
Working humidity 10 % to 90 %
Chassis 1U chassis
Dimensions 200 × 205 × 48 mm 285 × 215 × 48 mm
Weight (without hard disk) ≤ 1 kg

Of bekijk / or view datasheet HWN-2104H-4P/2108H-8P series NVR

Bekijk hier de handleiding van de (View manual of) network video recorder.
Beide zijn ook te vinden onder / Both can also be found under Support/Downloads/Hikvision.
