Hikvision HWI-B420H 4.0mm 2MP HiWatch Network Bullet camera

€ 107,00
HiWatch Series: 2 Megapixel IR Network Bullet camera
Beschikbaarheid: Op voorraad
SKU
HWI-B420H(4MM)(C)
  • 1/2.7" progressive scan CMOS
  • 1920× 1080
  • 4.0 mm lens
  • Horizontal FOV 90.2°, vertical FOV 48.6°, diagonal FOV 107.6°
  • Aperture F2.0
  • Video compression: Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG
  • Digital WDR (Wide Dynamic Range)
  • Image enhancement: BLC, 3D DNR (Digital Noise Reduction)
  • Smart supplement light, IR range up to 50 m
  • Day/Night switch: Day, Night, Auto, Schedule
  • Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • Motion detection, video tampering alarm, exception
  • Power 12 VDC ±25%, 0.4A
  • IP67
  • Material: Metal & plastic
  • Dimension: 83.7 mm × 80.7 mm × 206.6 mm
  • Client: iVMS-4200, Hik-Connect

Lees meer over / read more about Hikvision HiWatch series

Meer informatie
SKU HWI-B420H(4MM)(C)
Merk Hikvision
EANcode 6931847133160
HWI-B420H-4MM (C)
Camera
Image sensor 1/2.7"CMOS
Max Resolution 1920 x 1080
Min. Illumination Color: 0.01 Lux @(F2.0, AGC ON) 0 Lux with IR
Shutter time 1/3s to 1/100,000s
Day&Night IR cut filter
Angle adjustment Pan: 0° to 360°, tilt: 0° to 180°, rotation: 0° to 360°
Lens
Aperture F2.0
Lens mount M12
FOV 4 mm, horizontal FOV 90.2°, vertical FOV 48.6°, diagonal FOV 107.6°
Illuminator
IR range Up to 50m
Smart supplement light Yes
IR wavelength 850nm
Video
Main stream 50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub stream 50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Video compression Main stream: H.265/H.264/H.265+/H.264+
Sub-stream: H.265/H.264/MJPEG
Video Bit Rate 32 Kbps to 8 Mbps
H.264 type Baseline profile/Main profile/High profile
H.265 type Main profile
Region of interest (ROI) 1 fixed region for main stream
WDR Digital WDR
Day/Night Switch Day, Night, Auto, Schedule
Image Enhancement BLC, 3D DNR
Image Settings Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
Network
Simultaneous Live View Up to 6 channels
API Open Network Video Interface (Profile S), ISAPI
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
User/Host Up to 32 users
3 levels: Administrator, Operator and User
Client iVMS-4200, Hik-Connect
Interface
Ethernet Interface 1 RJ45 10M/100M self-adaptive Ethernet port
Event
Basic event Motion detection, video tampering alarm, exception
General
Storage conditions -30 °C to 60 °C. Humidity 95% or less (non-condensing)
Startup and operating conditions -30 °C to 60 °C, humidity: 95% or less (non-condensing)
Power 12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug PoE: (802.3af, Class 3, 36 V to 57 V), 0.15 A to 0.2 A, max. 6.5 W
Linkage method Upload to FTP, notify surveillance center, send email, trigger capture
Material Front cover: metal, body: plastic, bracket: metal
Dimensions Camera: 83.7 mm × 80.7 mm x 206.6 mm
With package: 260 mm × 125 mm × 125 mm
Weight Camera: approx. 420 g. With package: approx: 668 g
General function Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Approval
EMC CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014)
Safety CE-LVD (EN 62368-1:2014/A11:2017)
Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection IP67 (IEC 60529-2013)



Download: HikVision/HiWatch camera's
