Hikvision HWI-B180H 2.8mm 8MP HiWatch Network Bullet camera

€ 216,00
HiWatch Series: 8 Megapixel IR Network Bullet camera
Beschikbaarheid: Op voorraad
SKU
HWI-B180H(2.8MM)(C)
  • 1/2.8" progressive scan CMOS
  • 3840× 2160
  • 2.8 mm fixed focal lens
  • Horizontal FOV 108°; Vertical FOV 60°; Diagonal FOV 127°
  • Video compression: Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG
  • 120 dB WDR (Wide Dynamic Range)
  • Image enhancement: BLC, HLC, 3D DNR (Digital Noise Reduction)
  • Smart supplement light, IR range up to 30 m
  • Day/Night switch: Day, Night, Auto, Schedule
  • Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • Motion detection, video tampering alarm, exception
  • Power 12 VDC ±25%, 0.4A
  • IP67
  • Material: Metal & plastic
  • Dimension: 184.1 mm × 66 mm × 69.1 mm
  • Client: iVMS-4200, Hik-Connect

Lees meer over / read more about Hikvision HiWatch series

Meer informatie
SKU HWI-B180H(2.8MM)(C)
Merk Hikvision
EANcode 6931847140168
HWI-B180H-2.8MM (C)
Camera
Image sensor 1/2.8"CMOS
Max Resolution 3840 x 2160
Min. Illumination Color: 0.01 Lux @(F2.0, AGC ON) 0 Lux with IR
Shutter time 1/3s to 1/100,000s
Day&Night IR cut filter
Angle adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotation: 0° to 360°
Lens
Lens type Fixed focal lens, 2.8 mm
Aperture F2.0
Lens mount M12
Iris type fixed
FOV 2.8 mm, horizontal FOV 108°, vertical FOV 60°, diagonal FOV 127°
Illuminator
Supplement light range Up to 30m
Supplement Light type IR
Smart supplement light Yes
IR wavelength 850nm
Video
Main stream 50 Hz: 12.5 fps (3840 × 2160), 20 fps (2592 × 1944), 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 15 fps (3840 × 2160), 20 fps (2592 × 1944), 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub stream 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Video compression Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Video Bit Rate 32 Kbps to 16 Mbps
H.264 type Baseline profile/Main profile/High profile
H.265 type Main profile
Region of interest (ROI) 1 fixed region for main stream
WDR 120 dB
SNR ≥ 52 dB
Day/Night Switch Day, Night, Auto, Schedule
Image Enhancement BLC, HLC, 3D DNR
Image Settings Mirror, rotate, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Privacy Mask 4 regions of privacy mask
Network
Security Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, security audit log, TLS 1.2, host authentication (MAC address)
Simultaneous Live View Up to 6 channels
API Open Network Video Interface (Profile S), ISAPI, SDK
Protocols TCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, HTTPS, RTP, RTSP, NTP, UPnP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, 802.1x, SMTP
User/Host Up to 32 users
3 levels: Administrator, Operator and User
Client iVMS-4200, Hik-Connect
Interface
Ethernet Interface 1 RJ45 10M/100M self-adaptive Ethernet port
Event
Basic event Motion detection, video tampering alarm, exception
Linkage Notify surveillance center, trigger capture
General
Storage conditions -30 °C to 60 °C. Humidity 95% or less (non-condensing)
Startup and operating conditions -30 °C to 60 °C, humidity: 95% or less (non-condensing)
Power 12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5. mm coaxial power plug PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
Material Metal & plastic
Dimensions Camera: 184.1 mm × 66 mm x 69.1 mm
With package: 216 mm × 121 mm × 118 mm
Weight Camera: approx. 270 g. With package: approx: 489 g
General function Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Approval
EMC CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014)
Safety CE-LVD (EN 62368-1:2014/A11:2017)
Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection IP67 (IEC 60529-2013)



Downloadable @: HikVision/HiWatch camera's
